| Control Panels |
| |
MS-2(E)
2-Zone Fire Alarm Control Panels |
| |
| Conventional |
|
| General |
The Fire Lite MS-2 and MS-2E Fire Alarm Control Panels (FACPs) bring the latest in microprocessor technology to conventional fire controls. The MS-2 is compatible with the i³™ smoke detectors from System Sensor with drift compensation, maintenance alert, and freeze warning. Automatic synchronization of audio/visual devices with three selections for manufacturer protocol. The Notification Appliance Circuit (NAC) protocol can silence audible devices while strobes continue to flash, using a single pair of wires.
The MS-2 is compatible with conventional input devices such as two- and four-wire smoke detectors, pull stations, waterflow devices, tamper switches and other normally-open contact devices. Refer to the Fire•Lite Device Compatibility Document no. 15384 for a complete list of compatible devices.
|
|
Note: Unless indicated otherwise, the term “MS-2” refers to both MS-2 and MS-2E models. |
| |
| Features: |
|
| » |
Two Style B (Class B) Initiating Device Circuits (IDCs). |
| » |
One Style Y (Class B) NAC. |
| » |
24 VDC. |
|
|
|
|
|
| |
| * Click here more Information |
|
 |
|
| |
| ^ Top |
|
| |
MS-4(E)
Fire Alarm Control Panel |
| |
| Conventional |
| General |
The Fire Lite MS-4 and MS-4E Fire Alarm Control Panels (FACPs) bring the latest in microprocessor technology to conventional fire controls. The MS-4 is compatible with the i³™ smoke detectors from System Sensor, with drift compensation, maintenance alert, and freeze warning. Automatic synchronization of audio/visual devices with three selections for manufacturer protocol. The Notification Appliance Circuit (NAC) protocol can silence audible devices while strobes continue to flash, using a single pair of wires.
The MS-4 is compatible with conventional input devices such as two- and four-wire smoke detectors, pull stations, waterflow devices, tamper switches and other normally-open contact devices. Refer to the Fire•Lite Device Compatibility Document for a complete list of compatible devices.
|
|
|
Note:Unless indicated otherwise, the term “MS-4” refers to both MS-4 and MS-4E models. |
| |
| Features: |
|
| » |
Four Style B (Class B) Initiating Device Circuits (IDCs). |
| » |
Two Style Y (Class B) NACs. |
| » |
Optional module that converts all four IDCs and two NACs to Class A operation. |
| » |
24 VDC. |
|
|
|
|
|
| |
| * Click here more Information |
|
|
|
| |
| ^ Top |
|
| |
MS-5UD/MS-10UD(E) Series
Five Zone Fire Alarm Control Panel
Ten Zone Fire Alarm Control Panel |
| |
| Control/Communicators |
|
| General |
The MS-5UD-3 is a five-zone FACP (Fire Alarm Control Panel)
and the MS-10UD-7(E) is a ten-zone FACP. These control panels provide reliable fire signaling protection for small to
medium-sized commercial, industrial, and institutional buildings. Both panels include built-in communicators for Central Station Service and remote upload/download.
Each of these FACPs is compatible with System Sensor’s microprocessor-based i3 series detectors.
|
|
|
These conventional smoke detectors can transmit a maintenance trouble signal to the FACP indicating the need for cleaning and a supervisory “freeze” signal when the ambient temperature falls below the detector rating. Additionally, both the MS-5UD-3 and MS-10UD-7 are compatible with conventional input devices such as two- and four-wire smoke detectors, pull stations, waterflow devices, tamper switches, and other normally-open contact devices. Refer to the Fire•Lite Device Compatibility Document for a complete listing of compatible devices.
Outputs include four NACs (Notification Appliance Circuits), three programmable Form-C relays (factory programmed for Alarm, Trouble, and Supervisory) and 24 VDC special application resettable and nonresettable power outputs. The FACPs supervise all wiring, AC voltage, battery level and telephone line integrity. |
|
|
|
|
|
| |
