Entrance Control Systems
Tripod Turnstile
Application : Low to Medium level security installations, crowd  control.
Through put :
20-30 persons/minute (Approx), without access control 12-15 persons/minute with access control system
» Rotor arm height from ground : 863 mm
» 1200 stop (Tri Arm).
» Positive action lock to prevent multiple person access.
» Anti back-up device to prevent reverse rotation.
» Walkway 380mm (optional 500 mm)
» Available in Mild steel / Stainless steel cabinet
» Hydraulic damping (Regular)
» Motorized Drive Mechanism (Optional).
» Drop Arm Facility during emergency / power failure (Drop Arm Model)
^ Top
Retractable Flap Barrier
Application :
Entrance / Exit points of corporate houses, shopping mall, amusement parks etc. Where controlled access is essential but aesthetics & higher through put is of priority.
» Opening time  : Less than 0.8 seconds
» Passage Width : 520 mm for pedestrian movement.
    : 900 mm for wheel chairs / trolleys/ handicapped entry.
» Occupancy sensors for safety of persons.
» Torque controlled DC servo motor using latest PWM Technology.
» Normally closed mode of operation ( Normally open optional).
» Detection of ‘Tail –gating’(Optional).
